Carbon Block Filter Cartridges

Carbon Block Filter Cartridges

AmeriWater’s Carbon Block Filter Cartridges reduce natural organic contaminants in feed water.

Chlorplus Chloramine Filter Cartridges

Chloramine removal cartridge is ideal for portable RO and DI dialysis water treatment. Each cartridge is a special blended carbon block design rated at one micron filtration with 2000 gallons of capacity when flowing at 1 GPM at 3 PPM chloramine feed for each 10” of cartridge.

Features
  • Flow Rate (GPM): 1 GPM & 2 GPM
  • Capacity (chloramines): 6000 PPM
  • Dual Open End
  • Polypropylene End Caps
  • Buna-N Gaskets
  • Temperature Rating 40º F to 180º F
Model

20-5011: 1 µm micron rating, 2½inc x 10inc, 20-5011-12 model case, 12 per case
20-5012: 1 µm micron rating, 2½inc x 20inc, 20-5012-6 model case, 6 per case
20-5013: 1 µm micron rating, 4½inc x 10inc
20-5014 1 µm micron rating, 4½inc x 20inc

Chlorine/Organic Filter Cartridge for MRO1

Powdered activated carbon is extruded into a filter block with superior filtration and adsorption performance compared to GAC. The filter cartridges are built with pre-filtration wraps, polypropylene end caps and Buna-N gaskets in a double open end (DOE) design for excellent housing fit. The micron filtration efficiency is 85% of the rated particle size.

Operation Limits

Typical Operating Pressure: 20-100 PSI
Temperature Range: 40°F to 180°F
pH, Operating Optimum: 6-9
Product Permeate Flow: Not to Exceed Specification
Feed NTU: < 1

Model

20-5102: 10 µm micron rating, 2½inc x 20inc, 8 initial flow GPM, 20-5102-6 model case, 6 per case
